TFV 600 Radial Fan
The TFV 600 is a high-performance radial fan engineered for demanding ventilation, drying, and air-movement applications. Designed for powerful airflow over long distances, it delivers exceptional performance even in challenging industrial and commercial environments. With a robust, stackable housing and reliable continuous-duty operation, the TFV 600 ensures efficient air circulation for construction sites, refurbishment projects, event spaces, and emergency HVAC support.
Interested in hiring this product?
0808 169 1919Specification
Performance Data
| Max Airflow: | 16,000 m³/hr |
| Air Pressure Max.: | 4,900 Pa |
| Air Outlet Velocity: | 21 m/s |
| Air Discharge Speed: | 75.6 Km/h |
| Fluid Temperature Max.: | 80°C |
| Operating Range: | -20 / +40°C |
| Fan Type: | Radial |
| Control: | 1 Stage |
Connections
| Hose Connection: | - |
| Hose Length Max.: | - |
| Intake Nozzle: | 515 mm |
| Discharge Nozzle: | 515 mm |
Electrical
| Power Supply: | 415V 3Ø 50Hz |
| Plug Type: | 32A 5 pin BS4343 |
| Running Amps: | 34 A |
Physical
| Sound level: | 78 dBA |
| Weight: | 233 Kg |
| Dimensions (Length): | 1305 mm |
| Dimensions (Width): | 1250 mm |
| Dimensions (Height): | 1170 mm |
